Packaging & Delivery
| Packaging Details: | Waterproof, wooden box,according to costomers |
|---|---|
| Delivery Detail: | Shipped in 50 days after payment |
Steel Structure Electrical Metal Embossing Machinery
The Technical Parameters:
| Outline dimension | 3600*1300*1750mm |
| Roller size | Φ400*1400mm |
| The material of roller | 45#\40CrMo |
| Way of embossing | the male and female roller press each up and down |
| Pressing adjustment | by speed deducting gears |
| Motor power | 15KW |
| PLCspeed | 0~30m/min |
| Target of sheets | Aluminm sheet:≤2.0*1500mm Colorful sheet:≤0.7*1250mm
|
| Pattern | As per customer(double sides) |
We can provide the embossing according to the customer require.
1. High -precision feeder guarantee feeding stably and high efficency.
2. It is easy to operate machine and improve the work efficency greatly , working speed setting in advance.
3.The complete machine features humanization design.
4.Embossing aluminum sheet ,adopted double surface embossed patterns technique.
5.Profession embossing rice grain effect.(effect requirement brought foward by the costomers)
